型号 Model	出线孔尺寸 Slot Hole Size	宽×高 W×H(mm)	电线容量 Wiring Volume(PCS)	槽底固定孔 Mounting Hole Dimension	Download 图纸下载
GW-1525	(S/L)	15×25	5-12	Small	下载
GW-1616	(S/L)	16×16	3-10	Small	下载
GW-2020	(S/M/L)	20×20	5-12	Small	下载
GW-2060	(S/M/L)	20×60	5-12	Small	下载
GW-2516	(S/M/L)	25×16	5-12	Small	下载
GW-2525	(S/M/L)	25×25	10-25	Small	下载
GW-2540	(S/M/L)	25×40	20-25	Small	下载
GW-2545	(S/M/L)	25×45	20-25	Small	下载
GW-2565	(S/M/L)	25×65	40-45	Small	下载
GW-3333	(S/M/L)	33×33	25-54	Small	下载
GW-3345	(S/M/L)	33×45	40-55	Small	下载
GW-3365	(S/M/L)	33×65	60-75	Small	下载
GW-3816	(S/M/L)	38×16	12-13	Small	下载
GW-4025	(S/M/L)	40×25	20-25	Small	下载
GW-4040	(S/M/L)	40×40	60-70	Small	下载
GW-4060	(S/M/L)	40×60	100-115	Small	下载
GW-4080	(S/L)	40×80	120-135	Small	下载
GW-4545	(S/M/L)	45×45	60-70	Small	下载
GW-4565	(S/M/L)	45×65	110-120	Small	下载
GW-5050	(S/M/L)	50×50	80-90	Small	下载
GW-50100	(S/M/L)	50×100	210-260	Small	下载
GW-6040	(S/M/L)	60×40	100-115	Small	下载
GW-6060	(S/M/L)	60×60	120-135	Small	下载
GW-6080	(S/L)	60×80	180-210	Small	下载
GW-6545	(S/M/L)	65×45	110-120	Small	下载
GW-6565	(S/M/L)	65×65	180-200	Small	下载
GW-7264	(L)	72×64	200-220	Large	下载
GW-8040	(L)	80×40	120-135	Large	下载
GW-8060	(L)	80×60	180-210	Large	下载
GW-8080	(S/L)	80×80	240-290	Large	下载
GW-33100	(L)	33×100	180-200	Large	下载
GW-70100	(L)	70×100	250-300	Large	下载
GW-10050	(L)	100×50	200-250	Large	下载
GW-10060	(L)	100×60	240-290	Large	下载
GW-100100	(L)	100×100	300-400	Large	下载
GW-15075	(L)	150×75	335-500	Large	下载
